| Brand Name: | PHOENIX |
| Model Number: | VG AI Optical Sorter |
| MOQ: | 1 |
| Price: | Price Negotiable |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
The VG Intelligent Optical Sorter features an AI-driven RGB/MSI adaptive camera combination, capable of accurately detecting subtle differences in chickpea color, size, shape, and texture. The proprietary deep learning algorithm enables continuous iterative optimization, allowing defect recognition capabilities to evolve with new samples.
| Model | Chute | Air Nozzle | Air Pressure (MPa) | Air Consumption (L/min) | Power (kW) | Voltage | Dimension (LWH)(mm) | Weight*(kg) |
|---|---|---|---|---|---|---|---|---|
| VG1 | 1 | 64 | 0.6~0.8 | <1000 | 0.9 | 220V~ 50/60Hz | 1255*2199*2076 | 680 |
| VG4 | 4 | 256 | 0.6~0.8 | <2000 | 2.9 | 220V~ 50/60Hz | 2170*2199*2076 | 1150 |
| VG6 | 6 | 384 | 0.6~0.8 | <3000 | 4.4 | 220V~ 50/60Hz | 2800*2199*2076 | 1480 |
| VG8 | 8 | 512 | 0.6~0.8 | <4000 | 5.9 | 220V~ 50/60Hz | 3430*2199*2076 | 1840 |
| VG10 | 10 | 640 | 0.6~0.8 | <5000 | 7.3 | 220V~ 50/60Hz | 4070*2199*2076 | 2180 |
| VG12 | 12 | 768 | 0.6~0.8 | <6000 | 8.8 | 220V~ 50/60Hz | 4835*2199*2076 | 2550 |
✦ Customized Sorting Solution for Chickpeas
High-Efficiency Vibratory Feeder: Ensures a single-layer, even distribution of chickpeas, effectively reducing overlapping.
Industrial-Grade Dustproof Design: Sealed sorting chamber and electrical cabinet, built to perform reliably in high-dust environments.
Integrated Dust Control System: Proven and dependable, ensuring stable long-term operation.
Modular Chute Configuration: Available in 1, 4, 6, 8, 10, or 12 channels to flexibly match different capacity requirements.
✦ AI-Powered 4-in-1 Intelligent Optical Sorting System
Proprietary Deep Learning Algorithm: Continuously improves defect recognition by learning from new samples.
High-Resolution RGB Color Imaging: Captures even the finest defects on chickpeas.
High-Intensity LED Lighting: Delivers clear, stable, and consistent imaging.
Optional NIR or InGaAs-SWIR Cameras: For more complex inspection requirements.
✦ Market-Leading Defect Detection for Chickpeas (Based on color, size, shape, and texture)
Discolored kernels: Moldy, oxidized, immature, or contaminated chickpeas.
Broken / split chickpeas
Insect-damaged chickpeas
Diseased chickpeas: Kernels infected with fungal or bacterial spots.
Foreign materials: Stems, stones, glass, plastic, metal contaminants.
Supports fast switching of custom sorting parameters for multiple chickpea varieties.
✦ High-Performance Pneumatic Ejector System
Optimized design balancing durability, response speed, and air efficiency.
Maintains precise ejection and stable performance even under high-throughput conditions.
Significantly reduces the false rejection rate, lowering overall operating costs.
✦ 15 Industrial-Grade Touchscreen Control System
Intuitive HMI with multi-language support.
One-touch switching of sorting parameters for different chickpea varieties.
Comprehensive remote support system including:
Remote access and real-time monitoring
Performance data dashboard
Online expert diagnosis
Interactive fault troubleshooting
